Snail Tales – Building an Animatic – Part 2

no comment

In the previous post, I had set up the Jenkins build server, along with some of the dependencies required to extract the project.  In this post I’ll look at some of the challenges that will affect the ability to build Kdenlive video using a continuous integration approach.

Ch ch ch changes….

Firstly we need to know what files have changed since the last project was built.  For example if the project was last build on Monday night, then there may have been multiple check ins since that build, meaning that there are multiple scenes that have been checked in.  Conversely it may be that there have been no changes, or a single change that involves multiple files. Bazaar will allow us to get a list of affected files for a set of revision numbers :

bzr status -r1..4

Here bazaar will list the files that have changed between version 1 and version 4.  This content can be parsed for valid files, even looking for only specific file types (for example : SIF files).

  • If the file is present then that file has either been added or modified.  This scene would need to be rebuilt.
  • If the file is not present then that file has been deleted.  This scene cannot be rebuilt, and should be removed from the Kdenlive project.

Building Synfig Scenes

Synfig offers – in addition to the Synfig-studio user front end, the Synfig command line interface.  The man page for synfig shows that a synfig file can be rendered to a sequence of images for processing into a video clip.



synfig -t image <<tk – add proper command line settings here>>



Inserting video clips into a Kdenlive project.

Kdenlive projects are xml based – which is fortunate.  It is therefore possible to perform xpath queries on the tree to retrieve all of the referenced clips and resources.  It is also possible to rewrite these references to point to new file names for the recently generated video files.  There is a bit of a gotcha here.  All paths in kdelnive are full paths, and are not relative.  This has been a problem with the kdenlive project type for a while now.  There have been bugs raised about providing the ability to store paths a relative to the kdenlive project location – however the current method of resolving the issues presented by full reference paths has been to provide a path resolution process.  This allows the user to scan the file system for matching resources, and while a useful tool for fixing these issues, it ultimately becomes less usable in an automated build environment.  Therefore we need to make sure that these paths can be calculated and re-written – and the only real piece of information we have is that the project exists at a location.  Therefore convention will be important as this will allow the script to make assumptions about where resources should be located. Kdenlive has a unique way of storing paths.  At the project level, a “root” path can be stored.   Typically this is the first 2 directory levels, but should be possible to use a single level.  the actual resources have a path – with the root removed.  This means that the combination of the project root setting and the resource location gives the full path to the resource.  This then means that we need to split a root from the resource locations that are generated by the rendering process.







Rendering a Kdenlive project via the command line is possible.   The man page for kdenlive











Animatic Baker

Dave had set up his storyboard to use still frames taken using a digital camera. These were added to the Kdenlive work space and added to the timeline in order. By default Kdenlive creates a 5 second allocation for each shot when it is added to the timeline, but these can be stretched or squashed as appropriate. While this process works well for Dave, it causes a problem for Continuous integration. The files referenced are graphic files, and replacing them with video files causes a problem for kdenlive. The solution to this is to effectively ‘bake’ the animatic, replacing each graphic with a video clip of the correct duration. A replacement video can be rendered, overwriting the storyboard video, and when the project is rendered, that animatic now contains a replaced scene.
I worked on a python script that would investigate the Kdenlive project file, and extract filenames from paths, modify paths and update those file locations to the new location. Under the covers, the Kdenlive project is an xml file, and using lxml I could extract the sections of the file I was interested, apply changes to those sections and write the file back. Loading that Kdenlive file back into Kdenlive revealed the editor had an issue loading video files when the section of the file (2 sections called producer and kdenliveproducers) was originally a png (or indeed any other graphic) file.
I am currently working on a solution that constructs and replaced image based producer/kdenliveproducer sections with new sections based on the replacement clips – and will write more updates as I resolve these issues.
The challenges of animatic baking should only be experienced once during the project, so I decided to manufacture a storyboard by hand with replaced video clips. To create the replacement videos I used the following command line:

 avconv -loop 1 -i sb1_0001.png -vcodec libtheora -tune stillimage -t 41 OUTPUT_VIDEO.ogv
Here the video codec in use is Theora, tying into the original Snail Tales aim that the entire project be completed using open source and libre standards. Naturally other codecs are available, and could be substitued. Indeed for a production build a non-lossy format should be used – and in the end I opted to use a x264 render codec, as Kdenlive was experiencing difficulties reading the OGV file produced. It is also possible to use online resource to convert your video clips :
Video conversion functionality provided by video.online-convert.com/convert-to-ogg.

Video conversion functionality provided by video.online-convert.com/convert-to-ogg.



Wait – this is all getting somewhat complicated isn’t it?

Well – yes. It seems that the idea of continuously building the animatic based on updates to the scene source is not without it’s own set of challenges. – So how about a quick recap of where we are at.

  • I created a folder structure that will store the scenes, the artwork, the assets – basically everything needed to work on or build Snail Tales. The reason for that was that this allows animators and build services to consume the same content, and working with a disconnected system such as BZR would allow animators to add to their local repositories before pushing their scenes to the server.
  • I also created a copy of the animatic Kdenlive project, replacing the image shots with video shots. This would allow an animator to replace the finished scene into the animatic.
  • I’ve started writing a script that would automate much of this process (a process I call Baking) – but that’s still in progress.

So what else do we need to complete this utopian vision where animators check changes into a repository and a new animatic is produced automagically?

Scripting a build

the animatic needs to be build without user interaction. Ideally we should be able to run a script and the result should be a a video file is produced. Kdenlive is built on the MLT framework – a set of command line tools for interacting with video files, and kdenlive happens to expose that command line goodness, and even allows us to script a render through the rendering option.

KdenLive - Generate render Script

Kdenlive rendering options can generate a script for your render

Using this option I created a script and resource file – the imaginatively named animatic.sh and animatic.mlt.



Rewriting kdenlive Paths

If only kdenlive supported relative paths then that would be pretty much all we’d need, but unfortunately it doesn’t. What this means is that when Jenkins attempts to run the build script it is going to attempt to load video files from whatever location is in the file – in my case /home/mike/projects/snail-tales/animatic – which is fine if the server happens to be on the same server as the source matterials (which in my case it is). What we need to do is to modify those addresses to point to the workspace where jenkins checks out its files to build. Luckily we can do this in the build script within the Jenkins job for now, but I will probably move that functionality to a Python based solution, as much of the functionality relating to fixing paths would already be required for the animatic baker.
Accepting the current limitations on the solution, let’s get cracking with installing Jenkins then.

Installing Jenkins

Installing Jenkins under ubuntu is incredibly easy. I found a page by googling “install jenkins onto ubuntu”.
ultimately it boils down to :

wget -q -O - https://jenkins-ci.org/debian/jenkins-ci.org.key | sudo apt-key add -
sudo sh -c 'echo deb http://pkg.jenkins-ci.org/debian binary/ > /etc/apt/sources.list.d/jenkins.list'
sudo apt-get update
sudo apt-get install jenkins

Once installed you can access jenkins by pointing your browser to http://localhost:8080.
Screenshot from 2014-08-30 01:22:05

I installed the bzr source control plugin Manage Jenkins > Manage Plugins > Available > Bazaar Plugin.
Next I created a job.
SnailTales build job

This is where the process gets more complicated. As I mentioned before, In order for Jenkins to build out project correctly it will need to replace certain paths within the Kdenlive generated files – mainly relating to where the scene clips can be located, and where the output files should be saved. Therefore I wrote the following Script

#!/bin/bash
sed -i "s;/home/mike/projects/snail-tales/animatic;$WORKSPACE/animatic;" $WORKSPACE/animatic/animatic.kdenlive
sed -i "s;/home/mike/projects/snail-tales/animatic;$WORKSPACE/animatic;" $WORKSPACE/animatic/animatic.sh
$WORKSPACE/animatic/animatic.sh

This script uses sed to replace all references to the original location, to the new location based on the Jenkins Workspace. Jenkins has a concept called a workspace, which is an area on disk where jenkins will perform it’s work – including checking out bzr source code. Therefore the addresses for assets can be changed to point the folder location within the workspace rather than the original file location.
I initially create a schedule to build every 5 minutes – however I didn’t take into consideration that this would be accomplished by polling the source control system. This created a situation where the output was being re-rendered every 5 minutes whether it needed to or not. It also had an issue that if the build took longer than the job interval, that there would still be a second instance of the build started. This could have theoretically been resolved by forcing the job to use a specific executor – however I plan to replace this with a bzr hook. The act of checking in a change (to a particular file type) will force the rebuild of the animatic, or would enable the overnight scheduled build of the animatic – depending on how the system is configured. Trying to create a cron style schedule string is not exactly fun, and therefore I used a utility page at http://cron.nmonitoring.com/cron-generator.html to create the crontab style string for scheduling the build.

Gotchas

Kdenlive stores all path information as absolute paths – which when you are running the Jenkins server on the same machine mean that paths are still satisfied. But put that bzr repository on a network share, or even into lauchpad and those asset locations can’t be guaranteed to work. This is why the job re-writes part of the kdenlive files. As these files are xml files, it might be better / more efficient to redevelop these replacement scripts with something that uses xslt to update paths based on a selection criteria. Currently the mlt file still contains references to the source folder – these need to be modified in a similar way to the existing script – however there are slight changes. The MLT file has root attribute along with property elements with resource attributes. Together these make up a whole path. Having worked with xml for the Ubuntu Quickly Ebook Template, then there might be a possibility that some of the code could be re-used to modify the mlt files more effectively.

While developing the Snail Tales project structure, the test project experienced an issue where jenkins appeared to cut off early. Generated files were 14.3mb rather than 14.9mb. I believe this is a disk caching issue, or possibly related to Java.
For those that are interested – here’s what the animatic looked like once built :
